Lexmark 4227 - Forms Printer B/W Dot-matrix Service Manual page 127

4227-300
Part
Asm-
number
Index
2-1
40X3073
2 40X3098
3 40X3075
4 40X3082
5 40X3081
6 40X3121
7 40X3083
8 40X3132
9 40X3113
10 40X3079
11 40X3097
12 40X3074
13 40X3078
14 40X3080
15 40X3096
16 40X3099
17 40X3072
18 40X3052
19 40X3053
20 40X3097
21 40X3054
22 40X3055
23 40X2905
24 40X3120
Description
Feed roller, upper
Bearing kit
Frame support shaft
TOF & Paper Empty sensors with flags & springs
Paper guide/platen assembly
Bracket, Auto Gap motor
Roller, feed (lower)
Roller, pinch (lower)
Side frame assembly (left)
Sensor, Paper Select
Gear kit
Separator, paper
Latch, ribbon
Side frame assembly (right)
Screw, parts packet
Spring kit
Plate, carrier
Tractor side frame (left)
Tractor side frame (right)
Gear kit
Tractor pair with sensors (left and right)
Shaft kit, tractor
Paper Guide, tractor
Carrier motor cooling fan
7-5
Parts catalog
