Configure Data Drive - Intel SMALL BUSINESS SERVER Manual

3. Click Next in "RAID Web Console Package Setup" window
4. Read thru license agreement and make appropriate selection.
5. Click Next
6. Select StandAlone setup type and click Next
7. Leave selected components unchanged and click Next
8. Click Continue to install Java Runtime Environment
9. Click Install
10. In Setting Password window enter password that you would like to set for managing RAID.
You should not leave the password blank, as it can be used for managing the RAID
remotely.
11. Click Finish
NOTE: RAID Web Console can be accessed by typing
system reboot. To make any changes in RAID configuration, you will need to select Full Access. You may
want to create a shortcut for the RAID Web Console URL.
NOTE: If you experience problems logging into RAID Web Console in Full Access mode, use View Only
mode first without entering password, then click Exit, then login in Full Access mode with password.
NOTE: If hard-drive failure occurs, sound alarm on the RAID Controller will be activated.

Configure Data Drive

1. Right click on the My Computer icon and select Manage
2. Select Disk Management
3. Navigate to Disk 0 in the bottom plane, right-click on the Unallocated partition and choose
New Partition
4. Click Next in the Welcome to the New Partition Wizard.
5. At Select Partition Type select Primary Partition. Click Next
- 31 -
http://localhost:3570 in Internet Explorer after
