Server Hardware Integration

Instructions on how to integrate hardware are provided in Quick Start User's Guides and in Kit
Install Guides included in the boxes with mainboard, chassis, and kits. However, this guide helps
you to save time during hardware integration by providing integration guidance customized for the
hardware configuration specified in this guide.
Additional information on hardware integration can be found on the following pages:
Intel® Server Board S5000VSA
http://support.intel.com/support/motherboards/server/S5000VSA/howto.htm
Intel® Server Chassis SC5299-E
http://support.intel.com/support/motherboards/server/chassis/SC5299-E/howto.htm
Intel® RAID Controller SRCSU41L
http://support.intel.com/support/motherboards/server/srcu41l/index.htm

Preparing Slimline Drive Assembly

1. Unpack mounting kit for slim-line CD & USB floppy drives AXXCDUSBFDBRK
2. Unpack slim-line USB floppy drive AXXUSBFLOPPY
3. Unpack slim-line optical drive AXXDVDCDR ( or AXXSCD)
4. Follow instructions provided in Slimline USB Floppy/CD-ROM/DVD-ROM Drive Kit
Install Guide on pages 1-9.
5. Make sure that jumper on the optical drive backplane is in the Master position.

Preparing Chassis

1. Unpack and install second redundant power supply unit (APP4650WPSU) into an empty
slot at the rear of the chassis.
2. Follow steps 1 thru 7 described in Quick Start User's Guide included in the box with the
chassis.
On step 4 you should use Slimline Drive Assembly instead of CD-ROM/DVD-ROM. Use
DRIVE_0 connector on IDE cable for attaching to optical drive.

Installing Mainboard

1. If the mainboard was used previously, check that jumpers are set to correct positions: J1J1
– pins 1-2; J1J2 – pins 1-2; J3H1 – pins 2-3.
2. Follow steps 2 thru 8 described in Quick Start User's Guide included in the box with the
mainboard.
3. Re-install processor air duct as described in Step 9 of Quick Start User's Guide included in
the box with the chassis. Make sure that processor fans are attached to the mainboard
before re-installing the air duct.

Making Cable Connections to Mainboard

See mainboard Quick Start User's Guide for connector locations on the mainboard.
- 15 -
