Setting Boot Device Order - Intel SMALL BUSINESS SERVER Manual

22. Now in the lower plane you should see Array 1 and logical drive LD1 in Optimal state.
23. Click Exit and Yes to exit the RAID BIOS Console
24. Press <Ctrl><Alt><Del> to restart the system.

Setting Boot Device Order

1. During system boot up process press <F2> when "Press F2 to enter Setup" is displayed at
the top of the screen.
2. Wait until BIOS Setup is launched
3. Navigate to Boot Options tab
4. Set the following boot order
Primary Master CDROM
(Bus 06 Dev 01) PCI RAID Adapter
TEAC FD-05PUB 3000
IBA GE Slot 0500...
[EFI Shell]
5. Press <F10> and then <Enter> to save settings and reset the system
- 25 -
