Device Drivers and Utilities Installation
Video Driver Update
1. Browse to \1 – Video folder on Small Business Server Hardware Deployment CD
2. Run Setup.exe
3. In "ATI Display Driver Setup" window click Next.
4. Read thru license agreement and then click Yes to accept it.
5. In warning window click Continue Anyway.
6. After the installation process is complete select "No, I will restart the system later."
7. Click Finish.
8. Set appropriate screen resolution.
Chipset Drivers Installation
1. Browse to \2 – Chipset folder on Small Business Server Hardware Deployment CD
2. Run Setup.exe
3. Click Next in "Intel® Chipset Software Installation Utility" window
4. Read thru license agreement and then click Yes to accept it.
5. Click Next
6. After the installation process is complete select "No, I will restart the system later."
7. Click Finish.
Network Drivers Installation
1. Browse to \3 – LAN\apps\PROSETDX\Win32 folder on Small Business Server Hardware
Deployment CD
2. Run DxSetup.exe
3. Click Next in "Intel® PRO Network Connections" wizard
4. Read thru license agreement, make appropriate selection, and click Next.
5. Select Complete type of Setup and click Next
6. Click Install
7. Click Finish after the installation process is complete
Two onboard network interface cards will now be functional. Also additional tabs for advanced
configuration will now be available in device properties for NICs. For this solution you don't need
to use those advanced features.
RAID Web Console Installation
1. Browse to \4 – RAID Console folder on Small Business Server Hardware Deployment CD
2. Run setup.exe
- 30 -
