Technical Specification Update
II.
Summary Tables
The following tables provide a summary of known errata and planned documentation changes for each
of the following Intel products: Intel® Server Board SE7520JR2, Intel® Server Chassis SR1400, Intel®
Server Chassis SR1450, and Intel® Server Chassis SR2400. Where possible, Intel will correct existing
product errata with future product updates. Documentation changes will be made in future updates to the
given document. Please refer to the following notations as legend.
Doc:
Intel intends to update the appropriate document in a future revision.
Investigating
Intel is investigating the issue.
Fix:
Intel intends to fix this erratum in a future product update
This erratum has been addressed.
Fixed:
There are no plans to fix this erratum.
NoFix:
This erratum is either new or has been modified from the previous
Shaded:
specification update.
No.
Plans
Description of Errata
Memory Mirroring Not Supported by the System BIOS
1.
Fixed
Microsoft Windows* 2003 operating system shows 2 monitors in Device
2.
No Fix
Manager.
Some RAID controllers fail to recognize their Option ROM access hot-key
3.
Fixed
sequence needed to configure the card during POST
4.
Fixed
Platform Confidence Test (PCT) reports SIO error when no floppy drive is
present
5.
Fixed
Unknown Interrupt Error Message During POST
6.
Fixed
COM Port B Ring Indicator not terminated correctly.
7.
Fixed
BMC SEL Timestamp Incorrect Information
8.
No Fix
Current BIOS does not support Legacy Mode for the on-board Serial ATA (SATA) ports
9.
No Fix
Non-threshold base sensors mBMC responds threshold value
10.
Fixed
LM93 sensor monitoring issue
The silk screen identifying the PCI Slot numbers on the Low Profile PCI Riser card for the
11.
No Fix
SR2400 is not consistant with the silk screen of the full height PCI-X riser card.
12.
Fix
CPU 2 Processor Fault LED illuminated when no processor is installed
Silk screen for onboard SCSI Channels denote the internal SCSI connector as Channel A and
13.
No Fix
the external SCSI connector as Channel B. However, LSI firmware recognizes them in opposite
order.
Blinking
14.
Fixed
S7520JR2ATAD2 Server Boards
8
Table 3. Document Notation
Table 4. Summary of Known Product Errata
Green
Status
LED
Associated
with
FRUSDR
6.6.8
and
Summary Tables
Earlier
on
