Technical Specification Update
III.

Errata

1

Memory Mirroring Not Supported by the System BIOS

Problem The Memory Mirroring RASUM feature enabled by the Intel® E7520 Chipset is
not currently supported by the Intel Server Board SE7520JR2 BIOS.
Implication Customers will not be able to use the Memory Mirroring capability.
Workaround None.
Status Fixed. Intel has enabled this feature with system BIOS P07 and later
2 Microsoft Windows* 2003 operating system shows 2 monitors in
Device Manager.
Problem

Microsoft Windows* 2003 operating system shows 2 monitors in Device Manager.

Implication Under Windows* 2003, in Device Manager, 2 monitors will be shown as below:
1. Default monitor
2. Plug & play Monitor.
Workaround At this moment there is no workaround or fix for this. The reason two monitors
are showing up under Windows* is because the video BIOS used enables both
the CRT and DVI outputs of the ATI RageXL*. This is necessary to support the
Intel Management Module (IMM). Due to some architectural limitations with ATI
RageXL*, the DVI output cannot be turned off even when the IMM is not installed.
Status No Fix.
3 Some RAID controllers fail to recognize their Option ROM access hot-
key sequence needed to configure the card during POST
Problem Intel has determined a BIOS issue where some RAID controllers may fail to
recognize their Option ROM access hot-key sequence needed to configure the
card during POST.
Implication Configuring a RAID Array may not be possible
Workaround None
Status Fixed. Intel has corrected this issue starting with BIOS P07
10
Errata
