Documentation Changes

1 SATA drive activity LED is driven by both the backplane controller and
the Hard Drives
Problem In section 4.4.3 of Intel Server Chassis SR2400 Technical Product Specification
(TPS) and section 4.4.2.1.6 of Intel Server Chassis SR1400 Technical Product
Specification (TPS), the second sentence of the first paragraph will be updated
as "The LED on the SATA backplane is driven by both the backplane GEM424
controller and SATA drives themselves using pin 11 on the connector. Therefore
systems with newer SATA drives supporting pin 11 can support drive activity
regardless of what SATA controller is used."
Implication If using the onboard SATA controller of the baseboard, the Hard Drive will
determine if Activity LED is supported. Only newer SATA drives will have Pin 11
enabled to support drive activity monitoring. No drive activity will be displayed on
the Activity LED if using older SATA drives.
Status Doc. This will be added in a future release of Intel® Server Board SE7520JR2
TPS.
2

Incorrect description of 50-pin front panel connector as J1J2

Problem Table 92, page 190 of Intel® Server Board SE7520JR2 Technilcal Product
Specification (TPS) 1.0 labels the 50-pin front panel connector as J1J2. It should
state J1J1 as the proper reference.
Implication Misleading reference.
Status Doc. This will be corrected in a future release of Intel® Server Board SE7520JR2
TPS.
3 Incorrect pin assignment for table 90 "OEM RMC Connector Pinout
(J3B2)"
Problem Table 89, page 187 of Server Board SE7520JR2 Technilcal Product
Specification (TPS) 1.0 shows an inaccurate pin assignment for the J3B2
connector. The table should be as follow:
Pin
1
2
3
4
5
6
7
8
16
Table 90: OEM RMC Connector Pinout (J3B2)
Signal Name
PERIPH_I2C_3VSB_SDA
GROUND
PERIPH_I2C_3VSB_SCL
5V_STBY
POST_STATUS
ICH5_SYS_RST_L
+5V
FP_PWR_BTN_RMC
Documentation Changes
Description
