Novell NDS (if Novell client software is present)
●
Novell Bindery (if Novell client software is present)

LDAP Configuration

After selecting the authentication method on the Authentication tab, the LDAP configuration settings
appear. The device uses LDAP to retrieve the e-mail address for the authenticated user. After the
user has provided valid credentials, the software uses this information to match an attribute in the
LDAP database. After the match is made and the user is identified in the database, the user's e-mail
address is retrieved by using another database attribute. The LDAP settings include the following
options.
●
Options for configuring HP DSS to gain access to the LDAP server
●
Options for searching the database to obtain user e-mail addresses
To configure the LDAP server
1. Click Find Servers. The program searches the network for LDAP servers, and might also
prompt you for your network username and password, depending on the network configuration.
Next, the Select LDAP Server dialog box appears, containing a list of LDAP servers on the
network.
NOTE
environments. If the Find Servers process does not work, the TCP/IP address or
hostname of the Domain Controller or Global Catalog Server should be typed in the
LDAP Server text box. If the Global Catalog Server is used, the default LDAP port in the
Port text box must be changed to 3268.
2. Select the LDAP server to use. The information about the selected server appears.
3. Click OK to accept the selected server. The server information is filled in on the Authentication
tab.
4. Click Find Settings. The server settings appear in a dialog box. Click Yes to accept the settings.
5. Click Test on the Authentication tab to test the settings. In the Test User Authentication
dialog box, type in the network logon credentials of a user in order to test whether the user can
be authenticated and whether LDAP can successfully retrieve an e-mail address.
58 Chapter 3 Software features
The Find Servers option for finding LDAP servers does not work in all
