Configuring a workflow group

The first step in creating a workflow process is to create a workflow group.
NOTE
Group can also be used. This group cannot be deleted. Custom groups are optional and
provide a way to associate different workflows with different devices or groups of devices.
1. On the HP DSS server, open the HP MFP DSS Configuration Utility and click the Workflows tab.
2. Click Add Group. The Workflow Group dialog box appears.
3. Type the name of the new group. The name must be unique.
4. Click OK to save the new group.

Configuring a workflow menu

The second step in creating a workflow process is to create a workflow menu.
1. In the workflow tree, click a group to select it.
2. Click Add Menu. The Workflow Menu dialog box appears.
Figure 3-13
3. Type the name of the new menu. This name must be unique within the workflow group.
4. Select the style of the workflow menu. The style determines which options are available for
workflow forms within this workflow menu. The only available choice is Enhanced.
NOTE
additional Allow Nesting of Menus option under the Enhanced selection. Select this
option if you want to create multi-level workflow menus.
NOTE
For backward compatibility, the HP MFP DSS Configuration Utility can view and modify
these menus, but cannot create them.
5. Click OK to save the new workflow menu.
42 Chapter 3 Software features
Rather than creating a new group, the default group, called the Common MFP
Workflow Menu dialog box
In version 4.3 of the HP DSS program, the Workflow Menu dialog box has an
Only third-party workflow programs can create "Original" style workflow menus.
ENWW
