Guide View
Overlays two arrows onto the standard map
("Map View").
(1)
(2)
(15)
(4)
(11)
(5)
Route View
Displays the name of the street you will travel
along next and an arrow indicating the direction
of travel.
(1)
(2)
(15)
(4)
(11)
(5)
Vehicle Dynamics Display
Indicates the status of your vehicle.
❒ You can change the items indicated on the left
and right meters.
• In the Vehicle Dynamics Display mode,
the speedometer display may show a dif-
ferent speed than your vehicle's actual
speedometer, because your unit measures
speed in a different way.
➲ Setting the Vehicle Dynamics Display ➞
Page 67
36
(10) (8)
(7)
(16)
(12) (3) (9) (17) (6)
(10) (8)
(7)
(16)
(13)
(3)
(6)
(17)
(9) (12)

Rear View

Rear view image is displayed on of the screen.
❒ If you touch the screen briefly, the screen
changes Map View with shortcut menu. If
you close the shortcut menu the screen
returns to Rear View.
❒ If the "Camera" is set to "Off", the rear view
image is not displayed. Please set it to "On".
➲ Camera setting ➞ Page 125
❒ When using a camera set to turn ON/OFF in
conjunction with the reverse signal, no cam-
era images will be displayed in rear view mode
while you are moving forward.
❒ If the camera is set always ON, it can display
images in rear view mode when the vehicle is
moving forward. In that case, you should ask
the camera maker or dealer whether the cam-
era's functions or longevity would be affected.
Enlarged map of the intersection
When "Close-up of Junction" in the Settings
menu is "On", an enlarged map of the intersec-
tion appears.
(14)
❒ The system cannot be changed to an enlarged
intersection map in the following mode.
—Driver's View
—Vehicle Dynamics
—Rear View
(13)
