Tracking
Dots on the map indicating the route you have traveled.
VBR
VBR is short for variable bit rate. Generally speaking
CBR (constant bit rate) is more widely used. But by flexi-
bly adjusting the bit rate according to the needs of the
audio compression, it is possible to achieve compres-
sion with a priority on sound quality.
Voice guidance
The giving of directions by a recorded voice in guidance
mode.
Way Point
A location that you choose to visit before your destina-
tion; a journey can be built up from multiple way points
and the destination.
WMA
WMA is short for Windows Media™ Audio and refers to
an audio compression technology that is developed by
Microsoft Corporation.
WMA data can be encoded by using Windows Media
Player version 7 or later.
Windows Media and the Windows logo are trademarks
or registered trademarks of Microsoft Corporation in the
United States and/or other countries.

Specifications

General
Rated power source ............ 14.4 V DC
Grounding system ............... Negative type
Max. current consumption
................................... 10.0 A
Display unit:
Dimensions (W ✕ H ✕ D):
D
Chassis................. 178 ✕ 100 ✕ 165 mm
Nose...................... 170 ✕ 97 ✕ 8 mm
Weight .......................... 2.2 kg(4.9 lbs)
Navigation
GPS Receiver:
System.......................... L1, C/Acode GPS
Reception system ........ 8-channel multi-channel
Reception frequency ... 1 575.42 MHz
Sensitivity ..................... –130 dBm
Position update frequency
................................... Approx. once per second
GPS antenna:
Antenna........................ Micro strip flat antenna/
Antenna cable ............. 5.0 m(16 ft. 5 in.)
Dimensions (W ✕ H ✕ D)
................................... 33 ✕ 14 ✕ 36 mm
Weight .......................... 105 g(0.23 lbs)
Display
Screen size/aspect ratio ..... 6.1 inch wide/17:9
Pixels .................................... 336 960 (480 ✕ 234 ✕ 3)
Type ...................................... TFT active matrix, transmis-
Color system ........................ NTSC
Operating temperature range
........................................... +22
Storage temperature range
........................................... –40
Audio
Continuous power output is 22 W per channel minimum
into 4 ohms, both channels driven 50 to 15 000 Hz with
no more than 5% THD.
Maximum power output ..... 50 W ✕ 4
Load impedance.................. 4 Ω (4 Ω to 8 Ω [2 Ω for 1 ch]
(allowable voltage range:
12.0 V to 14.4 V DC)
(7 ✕ 3-7/8 ✕ 6-1/2 in.)
(6-3/4 ✕ 3-7/8 ✕ 3/8 in.)
SPS (Standard Positioning
Service)
reception system
right-handed helical polar-
ization
(1-1/4 ✕ 1/2 ✕ 1-3/8 in.)
(effective display area: 136 ✕
72 mm)
sive type
°F °F
to +185
°F to °F
+185
50 W ✕ 2 ch/4 Ω + 70 W ✕ 1
ch/2 Ω (for subwoofer)
allowable)
161
