Setting for rear view camera

The navigation system features a function that
automatically switches to the rear camera image
(REAR VIEW CAMERA IN jack) when a rear view
camera is installed on your vehicle. When the
shift lever is in REVERSE (R) position, the screen
automatically switches to a rear view camera.
(For more details, consult with your dealer.) You
can also use the camera as a rear view camera
(Rear View). In this case, you can see the image
of the rear view camera during normal driving.
• Pioneer recommends the use of a camera
which outputs mirror reversed images,
otherwise screen image may appear
reversed.
• Immediately confirm whether the display
changes to a rear view camera image when the
shift lever is moved to REVERSE (R) from
another position.
• When the whole screen changes to a rear view
camera image during normal driving, switch to
another setting.
❒ Initially, this function is set to Off.
1
Touch "Camera" in the System menu.
2
Touch "Camera" to turn rear view camera
setting on.
Touching "Camera" switches between "On"
and "Off".
❒ Unless this setting is "On", you cannot
switch to Rear View mode.
3
Touch "Polarity" to select an appropriate
setting for polarity.
Each time you touch "Polarity" switches
between the following polarity:
• Battery — When the polarity of the con-
nected lead is positive while the shift lever
is in the REVERSE (R) position
• GND — When the polarity of the connected
lead is negative while the shift lever is in the
REVERSE (R) position
Switching the auto antenna set-
ting
If the blue lead of the navigation system is con-
nected to the auto antenna of the vehicle, select
either of the following settings.
• Tuner — Extends the antenna only for the
Radio source. The antenna is stored when the
source is switched to another source.
• Power — Extends the antenna when the igni-
tion switch is turned on. The antenna is stored
when the ignition switch is turned off.
1
Touch "ANT CTRL" in the System menu.
Touching "ANT CTRL" switches between
"Tuner" and "Power".
❒ Regardless of whether "Tuner" or
"Power" is selected, turning off the igni-
tion switch will cause the antenna to auto-
matically retract.

Setting the illumination color

The illumination color can be selected from 11
different colors. Furthermore, the illumination
color can switch between the 11 colors in order.
1
Touch "Illumi Color" in the System menu.
2
Touch desired color.
• White/Light Green/Green/Light Blue/
Blue/Yellow/Amber/Red
• Memory1/Memory2/Memory3
— Colors registered in the memory
• Scan — Shifts between the eight default
colors in sequence
➲ "Creating a favorite color and registering it
to memory" ➞ Page 126
