Display during freeway driving
In certain locations of the freeway, lane informa-
tion is available, indicating the recommended
lane to be in to easily maneuver the next guid-
ance.
(18)
While driving on the freeway, freeway exit num-
bers and freeway signs may be displayed when in
the vicinity of interchanges and exits.
(19)

Display items

Guidance point*
The next guidance point (next turning point, etc.)
is shown by a yellow flag.
Destination*
A checker-flag indicates your destination.
(1) Name of the street to be used (or next
guidance point)*
(2) Distance to the guidance point*
Touch to access the next information.
(3) Current location
The current location of your vehicle. The tip of the
triangular mark indicates your heading and the
display moves automatically as you drive.
(4) Distance to the destination (or distance to
way point)*
If way points are set, the display changes with
each touch. When two or more way points are
set, the distance to the destination and the dis-
tance to the next way point are switched.
(5) Name of the street your vehicle is travel-
ing along (or City Name, etc.)
(6) Compass
The red arrow indicates north. If the scale is less
than 25 mi (50 km), touching the map changes
the direction that it is displayed in (north up/head-
ing up). When the scale of the map is greater than
25 mi (50 km), it is fixed to "north up".
(7) Zoom in/Zoom out
Touch to change the map's scale.
➲ "Changing the scale of the map" ➞ Page 38
(20)
(8) Map scale
The scale of the map is indicated by distance.
➲ "Changing the scale of the map" ➞ Page 38
(9) TRAFFIC icon
This appears when an XM tuner (GEX-P10XMT,
sold separately) is connected, and traffic informa-
tion is received.
(10) Current time
(11) Estimated time of arrival (or travel time
to your destination)*
The display alternates by pressing it.
The estimated time of arrival is automatically cal-
culated from the Average Speed set and the
actual average speed.
➲ How to set average speed ➞ Page 72
(12) Tracking mark
The tracking mark shows the route your vehicle
has traveled with dots.
➲ Select the tracking setting ➞ Page 74
(13) Map of your surroundings (Side map)
Touching the map briefly shows the shortcut
menu, while touching longer changes the map to
Scroll mode.
➲ "Moving the map to the location you want to
(14) Distance to a turning point*
Displayed on the enlarged intersection map. The
green bar gets shorter as your vehicle
approaches a turning point.
Heading up:
The map display always shows the vehicle's
direction as proceeding toward the top of the
screen.
North up:
The map display always has north at the top of
the screen.
see" ➞ Page 38
37
