Figure 1-79 Physical View; Shows a single Ethernet uplink from Port 1 on Module 1 to Port 1 on the first network
switch and a single uplink from Port 1 on Module 2 to Port 1 on the second network switch.
Item
Description
1
Switch Cross Connect
2
C7000 Enclosure, rear view
Scenario 1:7 – Private Networks (Simple vNet) 89
