Figure 1-55 Physical View; Shows two Ethernet uplinks from Ports 1 and 2 on Module 1 to Ports 1 and 2 on the first network
switch and two uplinks from Ports 1 and 2 on Module 2 to Ports 1 and 2 on the second network switch.
Item
1
2
Scenario 1:5 – VLAN Tagging (802.1Q) with a Shared Uplink Set (SUS) with Link Aggregation using LACP (802.3ad) –
Description
Switch Cross Connect
c7000 Enclosure, rear view
VMware ESX 63
