Appendix B: Scenario-based ProCurve
command line reference
Scenario 1-1 & 1-2 – ProCurve command line
configuration (Simple vNet with Active/Standby Uplinks)
Connect to the ProCurve switch servicing the VC-Enet uplink ports and enter the following commands.
NOTE: If t w o s w it ch es a r e b ein g u s ed , is s u e t h e s a m e com m a n d s on t h e s econ d s w it ch .
Table 1a
Command
>enable
#configure terminal
#span
#vlan 1 untagged [Ethernet] 1
#spanning-tree 1 admin-edge-port
#show interface brief 1
#show vlan ports 1 detail
#show vlan 1
#write memory
(For permanent changes only)
Scenario 1-1 and 1-2 (Part 1) - ProCurve command line configuration (simple network)
Shortcut
>en
#conf
#span
#vlan 1 untag 1
#span 1 admin-edge
#sh int br 1
# show vlan ports 1 detail
#sh vlan 1
#write mem

Appendix B: Scenario-based ProCurve command line reference 214

Description
Privilege mode
Configure in global mode
Enables spanning-tree (MSTP mode
by default)
Allow VLAN 1 on Port 1 , and set
Port 1 to untagged mode
Set Port 1 to be an edge port (non
bridging port). Note: port is set by
default in "auto-edge" mode which
automatically sets port to Edge if no
BPDU are received after 3 sec.
Display the status of Port 1
Displays the VLAN detail for Port 1
Display VLAN 1 port information
Save the running configuration to
NVRAM. Otherwise, the changes
will be lost on the next reboot.
