Juniper JUNOSE 11.2.X MULTICAST ROUTING Configuration Manual page 90

JunosE 11.2.x Multicast Routing Configuration Guide
show ip igmp oif-mapping
show ip igmp ssm-mapping
show multicast group limit
68
See show ip igmp oif-map.
Use to display the mapped OIF that is assigned to a given map-name, group address,
and source address.
Field descriptions
OIF-MAP Name—Name of the map requested
Group Address—Multicast group IP address requested
Source Address—Source IP address requested
Mapped OIF—Interface associated with the OIF map
Example
host1#show ip igmp oif-mapping OIFMAP 232.1.1.1 10.1.1.10
OIF Mapping
OIF-MAP Name
Group Address
Source Address : 10.1.1.10
Mapped OIF
See show ip igmp oif-mapping.
Use to display the SSM mapping state and the source list mapping associated with a
multicast group address.
Field descriptions
SSM Mapping—Status of SSM mapping on the interface: Enabled or Disabled
Group Address—Multicast group address requested
Source List—List of sources mapped to the multicast group address
Example
host1:boston#show ip igmp ssm-mapping 232.1.1.1
SSM Mapping : Enabled
Group Address : 232.1.1.1
Source List : 172.1.1.1
: 172.1.1.2
See show ip igmp ssm-mapping.
232.1.1.3/32 0.0.0.0/0
232.1.1.4/32 0.0.0.0/0
: OIFMAP
: 232.1.1.1
: ATM5/0.120
Copyright © 2010, Juniper Networks, Inc.
ATM5/0.130
ATM5/0.130
