JunosE 11.2.x Multicast Routing Configuration Guide
show ipv6 mld groups
host1:boston# show ipv6 mld groups
Grp Address
------------------- ---------------------- -------- --------------- ------ ------
ff0e::1 ATM2/0.15
ff0e::4:1 ATM2/0.15
Included Sources:
51::1
51::2
Counts: 2 version-2, 0 version-1, 0 check state, 0 disabled
(2 total)
0 excluded
Source-groups: 2 included, 0 excluded
192
enabled
2 total interfaces, 2 enabled, 0 disabled
2 enabled interfaces performing graceful restart
1 learned groups
MLD Statistics:
Rcvd: 1 total, 0 checksum errors, 0 unknown types, 0 discards
0 queries, 1 reports, 0 leaves
Sent: 2 total
See show ipv6 mld.
Use to display statically joined and directly connected groups learned through MLD.
Field descriptions
Grp Address—Address of the multicast group
Interface—Interface that discovered the multicast group
oif-map—Name of the OIF map and the mapped OIF interface, if a group or source
has been mapped to an OIF
State—MLD version of the group
Reporter—Link-local address of the host reporting the multicast group
ExpTim—Remaining time, in seconds, at which the router stops polling for more
members of this group
oldHTo—Remaining time at which the router stops polling for more MLDv1 members
of a group. If this value is 0, the interface has received no MLDv1 reports for the group.
Included Sources—Sources included in the multicast group
Excluded Sources—Sources excluded from the multicast group
Counts—Number of source-group mappings by version and state
Example 1—Without OIF mapping
Interface State
Version2 fe80::90:1a02:1 54
Version2 fe80::90:1a02:1 54
Example 2—With OIF mapping
Reporter ExpTim oldHTo
0
640:91d
0
640:91d
54
54
