Specifying Multicast Groups

ipv6 mld access-group
ipv6 mld access-source-group
Copyright © 2010, Juniper Networks, Inc.
You can use a standard IPv6 access list to specify the multicast groups that a host can
join.
Use to restrict hosts on this subnetwork to join only multicast groups that appear on
the specified IPv6 access list.
When configured, the access list is queried whenever the router receives an MLDv1
report requesting membership of a group and MLDv2 ChangeToInclude, IsInclude,
ChangeToExclude, or IsExclude reports. The request is ignored if the access list query
fails. The ipv6 mld access-group command uses IPv6 access lists, which allow both
source and destination/group addresses to be specified. You must set the source
address to " any."
Use the MLD-Access-Name RADIUS attribute (VSA 26-74) in RADIUS Access-Accept
messages as an alternative method of configuring this value.
Example
host1:boston(config-if)#ipv6 mld access-group boston-list
Use the no version to dissociate the interface from an access list and to allow hosts
on the interface to join any multicast group.
See ipv6 mld access-group.
Use to restrict hosts on this subnetwork to membership in those (S,G) pairs (also
known as " channels" ) permitted by the specified IPv6 access list.
When configured, both source and group addresses query the associated access list
whenever the router receives an MLDv2 report requesting membership of the (S,G)
pairs (that is, the router receives an MLDv2 ChangeToInclude, IsInclude, or
AllowNewSource group report). The request is ignored if the access list query fails. The
ipv6 mld access-source-group command uses IPv6 access lists, which allow both
source and destination group addresses to be specified.
Use the MLD-Access-Src-Name RADIUS attribute (VSA 26-75) in RADIUS
Access-Accept messages as an alternative method of configuring this value.
Example
host1:boston(config-if)#ipv6 mld access-source-group dallas-list
Use the no version to remove any access list restriction.
See ipv6 mld access-source-group.
