JunosE 11.2.x Multicast Routing Configuration Guide
ipv6 mld
ipv6 mld version

Configuring MLD Settings for an Interface

ipv6 mld immediate-leave
180
Enable MLD on the interface (MLDv2 is the default version).
1.
(MLDv1) Specify the MLD version for the interface.
2.
Use to enable MLD on an interface and to set the MLD version to MLDv2. Use the ipv6
mld version command to specify a different MLD version.
Example
host1:boston(config-if)#ipv6 mld
Use the no version to disable MLD on an interface.
See ipv6 mld.
Use to set the MLD version (1 or 2) for the interface.
Example
host1:boston(config-if)#ipv6 mld version 2
Use the no version to set the version to the default, MLDv2.
See ipv6 mld version.
When you start MLD on an interface, it operates with the default settings. You can,
however, modify:
The method that the router uses to remove hosts from multicast groups
The time interval at which the querier sends multicast listener queries
The time that a querier waits before sending a new query to hosts from which it receives
multicast listener done messages
The time that a non-querier waits for queries from the current querier before sending
query messages to assume responsibility of querier
The time that a host can take to reply to a query (maximum response time)
The number of times that the router sends each MLD message from this interface
