ip pim data-mdt
ip pim group-address-pool
mdt-data-delay
mdt-data-holddown
Copyright © 2010, Juniper Networks, Inc.
host1:pe1:pe13(config-route-map)#match ip address pe13DataMdtSend
host1:pe1:pe13(config-route-map)#set threshold 0
host1:pe1:pe13(config-route-map)#route-map pe13MdtThresholds permit 20
host1:pe1:pe13(config-route-map)#match ip address pe13DataMdt
host1:pe1:pe13(config-route-map)#exit
Configure the data MDT.
7.
host1:pe1:pe13(config)#ip pim data-mdt
host1:pe1:pe13(config-ip-pim-data-mdt)#tunnel source 1.1.1.1
host1:pe1:pe13(config-ip-pim-data-mdt)#tunnel group-address-pool pe13DataMdtG$
host1:pe1:pe13(config-ip-pim-data-mdt)#route-map pe13MdtThresholds
Use to activate data MDTs and enter IP PIM Data MDT Configuration mode.
Example
host1(config)#ip pim data-mdt
Use the no version to deactivate data MDTs.
See ip pim data-mdt.
Use to configure PIM group address pools from which data MDT group addresses are
allocated.
Example
host1(config)#ip pim group-address-pool pe21DataMDT 232.1.0.0 232.2.255.255
There is no no version.
See ip pim group-address-pool.
Use to configure a delay before switching to data MDT.
The delay is measured by 0.1 seconds; the default is 30.
Example
host1(ip-pim-data-mdt-config)#mdt-data-delay 20
Use the no version to return to the default.
See mdt-data-delay.
Use to configure the time in seconds before switching to the default MDT group from
the data MDT group.
The default is 60.
Example
host1(ip-pim-data-mdt-config)#mdt-data-holddown 200
