JunosE 11.2.x Multicast Routing Configuration Guide
host1:boston# show ipv6 mld membership
Flags: M Uses Oifmap
1,2 The version of MLD the group is in
Reporter:
<ip-address> - last reporter if the group is not explicitly tracked
<n>/<m> - <n> reporters include mode, <m> reporters in exclude
Group Source Reporter
--------- -------- ----------------------
ff0e::40 * fe80::90:1a02:1640:91d
ff0e::50 1/2
fe80::90:1a02:1640:911
fe80::90:1a02:1640:912
20::11
fe80::90:1a02:1640:913
20::12
fe80::90:1a02:1640:911
20::13
fe80::90:1a02:1640:911
fe80::90:1a02:1640:912
fe80::90:1a02:1640:913
ff0e::60 fe80::90:1a02:1640:901
10::10
10::11
10::12
10::14
198
Specify the tracked keyword to see interface information only for interfaces where
explicit host tracking is enabled.
Field descriptions
Group—Multicast group or (S, G) channel
Source—(S, G) entries that are forwarding traffic
Reporter—Hosts that requested including sources or that have not requested
excluding sources. If listed under a group, host that sent exclude reports for the group.
If listed under a source, host that requested traffic from this source for the group.
For any (S, G), if listed under a source, indicates hosts interested in the traffic for this
(S, G).
ExpTim—Expiration time
Flags
M—Uses Oifmap
S—SSM mapped
T—Tracked
1, 2—MLD version that the group is in
Interface—Type of interface and interface specifier. For details about interface types
and specifiers, see Interface Types and Specifiers in JunosE Command Reference
Guide.
Example
S SSM mapped T tracked
ExpTim Flags Interface
------ ------ ---------------
02:41 2S FastEthernet2/1
02:56 3MT FastEthernet2/2
02:30
02:48
02:56
02:30
02:30
02:48
02:56
01:56 3 FastEthernet2/3
02:45
02:35
02:15
stop
