JUNOSe 11.1.x Multicast Routing Configuration Guide
ip pim send-rp-announce
ip pim send-rp-discovery scope
92
Configuring an RP Router for PIM Sparse Mode and PIM Sparse-Dense Mode
Use the no version to clear the filter from this interface.
See ip pim rp-address.
Use to send auto-RP announcement messages from a router you configured as
an RP.
Specify an interface type and specifier, such as atm 3/0. For details about interface
types and specifiers, see Interface Types and Specifiers in JUNOSe Command
Reference Guide.
The auto-RP announcement messages contain the IP address for the interface
that you specify.
Specify the number of hops for which the announcement is valid; default value
is 64.
Specify an access list that details which multicast groups the RP can include in
announcement messages.
Specify a time interval in the range 1–65535 seconds to control how often the
router sends announcements. The default is 60 seconds.
Example
host1(config)#ip pim send-rp-announce loopback 2 scope 23 group-list boston
interval 200
Use the no version to clear filters from this interface.
See ip pim send-rp-announce.
Use to configure the router as an RP mapping agent, which records group-to-RP
mappings and notifies PIM designated routers about the mappings.
Specify the number of hops for which the RP discovery message is valid; default
value is 64.
To assign an interface from which the router sends auto-RP discovery messages,
specify an interface type and specifier, such as atm 3/0. For details about interface
types and specifiers, see Interface Types and Specifiers in JUNOSe Command
Reference Guide.
Example
host1(config)#ip pim send-rp-discovery scope 23 loopback 1
Use the no version to stop the router from acting as an RP mapping agent.
See ip pim send-rp-discovery scope.
