Monitoring Optimized Multicast Packet Replication; Port Statistics; Ip And Vlan Statistics - Juniper JUNOSE 11.1.X MULTICAST ROUTING Configuration Manual

ipv6 multicast ioa-packet-replication
ipv6 unnumbered

Monitoring Optimized Multicast Packet Replication

This section describes how to monitor hardware multicast packet replication.

Port Statistics

Use the show interfaces gigabitEthernet command to display port statistics for port
8. For port 8, queue statistics have no direct relationship to any of the 8 ports because
each packet transmitting through the queue can be sent through 1 or more of the 8
physical ports. For more information, see Monitoring Ethernet Interfaces in JUNOSe
Physical Layer Configuration Guide.

IP and VLAN Statistics

Use the show vlan subinterface command to display statistics for a VLAN interface
configured over port 8. For more information, see Monitoring Ethernet Interfaces in
the JUNOSe Physical Layer Configuration Guide.
Use the no version to set the version to the default, MLDv2.
See ipv6 mld version.
Use to configure hardware multicast packet replication on port 8 of a high-density
Ethernet module.
Example
host1(config-if)#ipv6 multicast ioa-packet-replication gigabitEthernet 3/8.1
Use the no version to disable hardware multicast packet replication.
See ipv6 multicast ioa-packet-replication
Use to configure an unnumbered IPv6 interface.
This command enables IPv6 processing on an interface without assigning an
explicit IPv6 address to the interface.
You must specify an interface location, which is the identifier of another interface
on which the router has an assigned IPv6 address. This interface cannot be
another unnumbered interface.
Example
host1(config-if)#ipv6 unnumbered loopback 10
Use the no version to disable IPv6 processing on the interface.
See ipv6 unnumbered.
Chapter 5: Configuring IPv6 Multicast
Configuring Hardware Multicast Packet Replication
167
