RV TV Mount
Instruction Manual
SKU: MOUNT-VWRV2
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vwrv2
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOUNT-VWRV2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo MOUNT-VWRV2

  • Page 1 RV TV Mount Instruction Manual SKU: MOUNT-VWRV2 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vwrv2 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 INSTALLATION LOCATIONS TV mount can be installed on the inside or outside of an RV or camper wood stud walls. If mounting on an RV, locate the designated mounting location which should be pre-labled by manufacturer as TV BACKER or TV MOUNTING LOCATIONS. Refer to RV maufacturer for more information.
  • Page 4 STEP 2 Measure the VESA pattern on your display to determine the correct installation orientation needed. Follow instructions that match your VESA pattern below: 100x100mm up to 200x200mm Patterns 100x100mm to 200x200mm, no extensions are required. Proceed to STEP 3. 400x300mm &...
  • Page 5 STEP 2 - Continued 300x300mm & 400x400mm To achieve a 300x300mm or 400x400mm VESA pattern setup, install Extension Arm Set (A) to inner holes on VESA Plate (B) using M6x11mm Carriage Bolts (S-A) with Washers (S-B) and M6 Nuts (S-C). Tighten using Wrench (T-A). 300x300mm 400x400mm 400x200mm...
  • Page 6 STEP 3 Flat Back Monitors Secure VESA plate assembly to the back of your display using appropriate Screws (M-A through M-H). Tighten screws using a Phillips Screwdriver. M-A - M-H M-A - M-H Recessed Back Monitors Secure VESA plate assembly to the back of your display using appropriate Screws (M-A through M-H) with Washers (S-B) and Spacers (M-I).
  • Page 7 STEP 4 Any cables needed should be plugged in prior to mounting the TV due to the low-profile nature of the mount. Once cables are plugged in, Slide the TV with VESA Plate (B) onto Wall Plate (C). Quick Release...
  • Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
