Full Motion Extra Large TV Wall Mount
Instruction Manual
SKU: MOUNT-VW120M
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vw120m
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo MOUNT-VW120M
Summary of Contents for Vivo MOUNT-VW120M
- Page 1 Full Motion Extra Large TV Wall Mount Instruction Manual SKU: MOUNT-VW120M Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vw120m GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete If unsure, please contact us at vivo-us.com, email at help@vivo-us.com, or call us at 309-278-5303. WARNING: CHOKING HAZARD SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS.
- Page 3 ASSEMBLY STEPS STEP 1 Stud Mounting: Concrete/Brick: Find desired mounting location using a stud Find desired mounting location and hold or tape finder. Hold or tape Mounting Template (E) up Mounting Template (E) on the wall using Bubble Level (T-A) ensuring the template is level. Mark to the desired mounting location using Bubble Level (T-A) ensuring the Template is level.
- Page 4 STEP 2 VESA Patterns Greater Than 200mm in Width: Place Left & Right VESA Brackets (B,C) onto the back of TV, so that the Locking Arms (B1, C1) are closest to the center of the display. Secure using appropriate screws (M-A thru M-D), M8 Washers (M-E), and a Phillips Screwdriver.
- Page 5 STEP 3 Ensure Locking Arms (B1, C1) are in the open position, facing downward, and place the TV with VESA brackets onto Mount (A) with assistance. Move Locking Arms (B1, C1) on VESA Brackets to locking position, pointing upward, and secure with M4x8mm ThumbScrews (S-A).
- Page 6 STEP 4 Route cables through Cable Cover (A1) on underside of Mount (A) and secure with Velcro Straps (D). STEP 5 To ensure the TV is level, use Wrench (T-B) to slightly loosen the screws on the back of the mount head. This will allow the TV to rotate.
- Page 7 STEP 6 Loosen screws on side of the mount head with Wrench (T-B) to adjust the tilt.
- Page 8 AVG. RESPONSE TIME (within office hrs): 1HR 8M - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
