Extra Large TV Wall Mount
Instruction Manual
SKU: MOUNT-VW70F
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vw70f
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo MOUNT-VW70F
Summary of Contents for Vivo MOUNT-VW70F
- Page 1 Extra Large TV Wall Mount Instruction Manual SKU: MOUNT-VW70F Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vw70f GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete walls. If unsure, please contact us at vivo-us. com, email at help@vivo-us.com, or call us at 309-278-5303.
- Page 3 DO NOT EXCEED WEIGHT CAPACITY. 154lbs Failure to do so may result in serious injury. (70kg) ASSEMBLY STEPS STEP 1 Extend wall plate (A) to full height, and secure straightened arms with screws (B). STEP 2 OPTION A: Wood Wall Installation Attach level (D) to wall plate (A), then use wall plate to mark mounting holes on wall where studs are located.
- Page 4 STEP 2 (Continued) OPTION B: Concrete/Brick Wall Installation Attach level (D) to wall plate (A), then use wall plate to mark mounting holes on wall. Using a 3/8” bit, drill 2.4” into wall. Insert anchors (W-B) into holes and use wall screws (W-A) and washers (W-C) to install plate.
- Page 5 STEP 3 (Continued) OPTION B: Curved Back Monitor Mount brackets (C) to back of television using bolts (M-C, M-D, M-E), washers (M-G) and spacers (M-H, M-I). Make sure cords are towards bottom of TV. M- C M- D M- I M- H M- G M- G...
- Page 6 STEP 4 Attach TV to wall plate (A) as shown in diagram. Make sure bottom of brackets (C) are attached securely. Cords can be hidden by hanging from brackets as shown.
- Page 7 STEP 5 To remove TV, pull both straps down and lift TV off of wall plate (A).
