TV Wall Mount
Instruction Manual
SKU: MOUNT-VW06
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vw06
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-VW06
Summary of Contents for Vivo MOUNT-VW06
- Page 1 TV Wall Mount Instruction Manual SKU: MOUNT-VW06 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vw06 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
-
Page 2: Package Contents
CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete walls. If unsure, please contact us at vivo-us. com, email at help@vivo-us.com, or call us at 309-278-5303. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 OPTION A: Wood Wall Use mount (A) to mark mounting holes on wall where stud is located. Using a 3/16” bit, drill approximately 2.2” into marked locations. Secure mount (A) to wall using bolts (W-A) and washers (W-C). - Page 4 STEP 2 Attach plastic cover to mount (A). STEP 3 Attach cable management clip (F) as shown in diagram.
- Page 5 STEP 4 Mount VESA adapters (C) and (D) to VESA plate (B) using bolts (I) and nuts (H) in the appropriate configuration to match your television’s mounting holes. STEP 5 Mount VESA plate (B) to back of TV using bolts (M-A, M-B, M-C) and washers (M-E, M-F).
- Page 6 STEP 5 (Continued) If bolts are too long, spacers (M-G) may be required as shown in diagram. STEP 6 Attach TV to mount (A) using nuts (J).
- Page 7 STEP 7 Adjust mount (A) using allen wrench (G) and wrench (E). Adjust as Desired...
