Under Desk Height Adjustable Keyboard Tray
Instruction Manual
SKU: MOUNT-KB27HB
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-kb27hb
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
309-278-5303
Chat live with an agent!
Advertisement
Related Manuals for Vivo MOUNT-KB27HB
Summary of Contents for Vivo MOUNT-KB27HB
- Page 1 Under Desk Height Adjustable Keyboard Tray Instruction Manual SKU: MOUNT-KB27HB Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-kb27hb GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
- Page 3 ASSEMBLY STEPS STEP 1 Assemble Keyboard Tray Set (A) using Connecting Plates (E), M5x12mm Flat Head Screws (S-C), and a Phillips screwdriver. Attach Keyboard Stop (F) to the back of Keyboard Tray Set (A) using M5x12mm Screws (S-C) and a Phillips screwdriver. STEP 2 Assemble Support Brackets (D) to the Slider Brackets (B) using M4x7mm Screws (S-A), making sure the counter sunk holes on Support Brackets (D) are facing outward.
- Page 4 STEP 3 Assemble Slider Brackets (B) to the Keyboard Tray Set (A) using M5x12mm Screws (S-B) and tighten with a Phillips screwdriver. The Support Brackets (B) should be installed to where they protrude out past the tray from the side with the Keyboard Stop (F).
- Page 5 STEP 4 ** NOTE: Mounting Brackets can be assembled facing inward or out, depending on your installation needs. Follow appropriate assembly steps below. *** OUTWARD INSTALLTION Connect the Mounting Bracket Set (C) to the side of Support Brackets (D) at your desired height, with Brackets extending away from keyboard tray, using M5x8mm Flat Head Screws (S-D) and a Phillips screwdriver.
- Page 6 STEP 5 - Outward Facing If Mounting Bracket Set was assembled facing outward in STEP 4, follow steps below for mounting. Hold Mounting Template (G) to the underside of desktop, aligned with the outer edge and use the outer holes on Template to mark holes. Remove Template and predrill holes using ⅛”(3mm) drill bit. Desktop Install keyboard tray to desk using M5x16 mm Screws (S-F) and a drill with a Phillips head drive bit.
- Page 7 STEP 5 - Inward Installation If Mounting Bracket Set was assembled facing inward in STEP 4, follow steps below for mounting. Hold Mounting Template (G) to the underside of desktop, aligned with the outer edge and use the inner holes on Template to mark holes. Remove Template and predrill holes using ⅛”(3mm) drill bit. Desktop Install keyboard tray to desk using M5x16 mm Screws (S-F) and a drill with a Phillips head drive bit.
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
