Satel CA-64 EPS Manual
Hide thumbs Also See for CA-64 EPS:

Advertisement

CA-64 EPS
ca64eps_int 02/14
EKSPANDER WEJŚĆ Z ZASILACZEM
PL
ZONE EXPANDER WITH POWER SUPPLY
EN
LINIENERWEITERUNGSMODUL MIT NETZTEIL
DE
МОДУЛЬ РАСШИРЕНИЯ ЗОН С БЛОКОМ ПИТАНИЯ
RU
РОЗШИРЮВАЧ ЗОН З БЛОКОМ ЖИВЛЕННЯ
UA
MODULE D'EXTENSION DE ZONES AVEC BLOC D'ALIMENTATION
FR
ZONE UITBREIDING MET VOEDING
NL
ESPANSIONE DI INGRESSI CON ALIMENTATORE
IT
MÓDULO DE EXTENSIÓN DE ZONAS CON FUENTE DE ALIMENTACIÓN
ES
ZÓNOVÝ EXPANDÉR S NAPÁJECÍM ZDROJEM
CZ
EXPANDÉR VSTUPOV SO ZDROJOM
SK
ΕΠΕΚΤΑΣΗ ΖΩΝΩΝ ΜΕ ΤΡΟΦΟΔΟΤΙΚΟ
GR
ZÓNABŐVÍTŐ BEÉPÍTETT TÁPEGYSÉGGEL
HU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CA-64 EPS and is the answer not in the manual?

Questions and answers

Summary of Contents for Satel CA-64 EPS

  • Page 1 CA-64 EPS ca64eps_int 02/14 EKSPANDER WEJŚĆ Z ZASILACZEM ZONE EXPANDER WITH POWER SUPPLY LINIENERWEITERUNGSMODUL MIT NETZTEIL МОДУЛЬ РАСШИРЕНИЯ ЗОН С БЛОКОМ ПИТАНИЯ РОЗШИРЮВАЧ ЗОН З БЛОКОМ ЖИВЛЕННЯ MODULE D’EXTENSION DE ZONES AVEC BLOC D’ALIMENTATION ZONE UITBREIDING MET VOEDING ESPANSIONE DI INGRESSI CON ALIMENTATORE MÓDULO DE EXTENSIÓN DE ZONAS CON FUENTE DE ALIMENTACIÓN...
  • Page 5: Status Led

    The CA-64 EPS zone expander can be used in conjunction with CA-64, INTEGRA and VERSA control panels. This manual applies to the expander with electronics version 2.3 and firmware version 4.00 (or newer). FEATURES • 8 programmable zones: – support for NO and NC type detectors, as well as roller shutter motion detectors and vibration detectors;...
  • Page 6: Dip Switches

    Use the switch 8 to define how the expander will be identified by the control panel: OFF – CA-64 EPS. The expander does not support roller shutter motion detectors and vibration detectors. Programming the end-of-line resistors value is not available.
  • Page 7: Installation And Start-Up

    FIGURE 2. Examples of address setting (address 14 (0Eh) is one of the addresses required for interaction with the VERSA series control panels). FIGURE 3. Connecting power supply. INSTALLATION AND START-UP Disconnect power before making any electrical connections. Never connect two devices with a power supply unit to one transformer.
  • Page 8: Specifications

    system (zone numeration rules are described in the alarm control panel manual). Note: If it is necessary to disconnect power supply from the expander, disconnect the mains first and the battery after that. To re-connect power supply, follow the procedure described above. SPECIFICATIONS Number of programmable zones Supply voltage...
