10 | Installation
Installer reference guide
122
Number of
units
Gas exhaust
10
11
12
13
14
15
16
17
18
19
20
For EHY2KOMB32AA:
Number of
units
Gas exhaust
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Special remark regarding C
to be 200×200 mm.
Concentric
Air intake
219 410
228 427
237 444
246 461
255 478
264 494
272 509
281 526
290 543
299 560
308 577
Concentric
Air intake
155 291
166 311
176 330
186 349
196 367
206 386
216 404
226 423
236 442
247 463
257 482
267 500
277 519
287 538
297 556
307 575
317 594
328 614
338 633
: The minimum inner dimensions of the chimney have
93
Dual pipe
Gas exhaust Air intake
219 347
228 361
237 375
246 389
255 404
264 418
272 431
281 445
290 459
299 473
308 488
Dual pipe
Gas exhaust Air intake
155 246
166 263
176 279
186 295
196 311
206 326
216 342
226 358
236 374
247 391
257 407
267 423
277 439
287 454
297 470
307 486
317 502
328 519
338 535
EJHA04AAV3 + EHY2KOMB28+32AA
Daikin Altherma H Hybrid
4P531180-1D – 2025.03
