- Page 1 SUBMERSIBLE SEWAGE PUMP 3/4HP CAST IRON SUMP 8400GPH MAX 28FT SKU: 76062 E248578 QSB-JH-1300215 LISTED 76062 26XZ ASSEMBLY...
-
Page 3: Customer Service
CUSTOMER SERVICE... - Page 4 30’...
- Page 5 Attention danger Not connected Power up Observez Clean Water Maintenance Stop Connected Environment...
- Page 7 Grain Size 2 INCH...
- Page 8 Dear clients, Please read and follow the original copy of the Operation Manual first before operating the device for the first time, and pay attention to keep the Manual for convenient use in the future or for other users. Legal Use The submersible pump is designed for personal use, not for industrial use.
- Page 9 Danger Cause immediate danger of serious damage to the body or even death. Alarming Hidden dangerous condition, may cause serious damage to the body or even death. Cautions: Hidden dangerous condition may cause slight injury or damage to the body.
- Page 10 Life Danger If you don't follow the safety tips, life danger with electricity may occur. Check if there is any damage of the connecting wire with plug before each run. If so, change the damaged connecting wire immediately by authorized client service center or electrical professionals.
- Page 11 Pump Instruction 1. Lift ring handle 2. Power line 3. Pump case 4. Base 5. Floating balls 6. Water pump outlet Preconditions To guarantee normal operation of the pump, the following preconditions must be satisfied: The outlet of the pool should be no smaller than 11 × 9.45 INCH in The water level is higher than 9.65 INCH so that the pump can pump the water fast.
- Page 12 As shown in the Figure B. The max submersible depth (h1) stands for the max installation water depth of the pump (if the placing depth of the pump is deeper than the nominal value on the nameplate, it may reduce the service life of the pump or let motor cavity inflow water.) The conveying height (h2) stands for the height difference from water level to outlet end of the water tube.
-
Page 13: Maintenance
Plug in the power supply. When the water level rises to drive the float up to a certain place, the switch turns on automatically and the water pump starts to work; when the water level falls to drive the float down to a certain place, the switch turns off and the pump stops working. - Page 14 Cautions: To avoid accident and damage, pay attention the weight of the device during carrying. Vehicle Transport Make sure the pump will not slip down, be squeezed and vibrate during transportation. Storage Cautions: To avoid accident and damage, pay attention the weight of the device when selecting the storage location.
- Page 15 Danger To avoid any damage, only approved client server center is permitted to maintain the pump. Make sure to power off the pump and unplug the plug before any operation to the pump. Fault Reason Trouble shooting The pump runs There is air in the pump Plug and unplug the power cord multiple but doesn't...
- Page 16 Model 76062 Voltage & Frequency 115V / 60Hz Current Power 3/4 HP Max. Pump Rate 8400 GPH Max. Height 28 FT Max. Grain Size 2 INCH Dia. Of Pipe NPT 2 Water Temperature 95 °F IPX 8 Protection Type Outlet...
- Page 18 253002067 Power cord 0010 207000754 Cross head tapping screw 0020 201005571 Pin assembly 0030 O-ring 0040 208001257 Sealing bolt 0050 201001697 O-ring 0060 208001222 0070 206000007 Ring handle 0080 207000196 Hexagon socket head cap screws 0090 207000487 Spring washer 0100 205000420 Motor case 0110...
-
Page 19: Please Read The Following Carefully
PLEASE READ THE FOLLOWING CAREFULLY The manufacturer and/or distributor have provided the parts list and assembly diagram in this manual for reference purposes only. They do not make any representation or warranty to the buyer that they are qualified to make repairs to the product or replace any parts of the product. In fact, the manufacturer and/or distributor expressly state that all repairs and parts replacements should be undertaken by certified and licensed technicians, and not by the buyer.
