XtremepowerUS 71093 Installation And User Manual

3.5cfm 1/4hp/4.5cfm 1/3hp refrigerant vacuum pump
Hide thumbs Also See for 71093:

Advertisement

Quick Links

3.5CFM 1/4HP REFRIGERANT VACUUM PUMP
4.5CFM 1/3HP REFRIGERANT VACUUM PUMP
2 0 0
m l
1 0 0
m l
INSTALLATION AND USER'S GUIDE
DANGER
Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future reference.
SKU: 71093 / 71095 / 71096
71093
71095
71096

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 71093 and is the answer not in the manual?

Questions and answers

Summary of Contents for XtremepowerUS 71093

  • Page 1 3.5CFM 1/4HP REFRIGERANT VACUUM PUMP 4.5CFM 1/3HP REFRIGERANT VACUUM PUMP SKU: 71093 / 71095 / 71096 2 0 0 1 0 0 71093 INSTALLATION AND USER’S GUIDE 71095 71096 DANGER Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
  • Page 2 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS CUSTOMER SERVICE Customer Service and Technical Support IMPORTANT SAFETY INSTRUCTIONS Legends and Symbols GENERAL SAFETY OVERVIEW (PRODUCT INFORMATION) PACKAGE CONTENTS SPECIFICATIONS OPERATION VACUUM PUMP OPERATING INSTRUCTIONS COMPONENTS AND FUNCTIONS FEATURES MAINTENANCE SAFETY WARNINGS AND MAINTENANCE INSTRUCTIONS INSPECTIONS CLEANING PROCEDURES STORAGE GUIDELINES...
  • Page 4: Important Safety Instructions

    NOTE hazards. USE OF NON-XTREMEPOWERUS REPLACEMENT PARTS VOIDS WARRANTY ATTENTION INSTALLER: This manual contains vital information regarding the installation, operation, and safe use of this pump. It is essential to provide this manual to the end user of the product. Failure to read and follow all instructions could lead to severe injuries.
  • Page 5: General Safety

    IMPORTANT SAFETY INSTRUCTIONS WARNING IMPORTANT SAFETY NOTICE • The warnings and safety instructions in this manual are not intended to cover all possible conditions and situations that may arise. Use common sense, caution, and care when operating or cleaning tools and equipment.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS WARNING TO PREVENT PERSONAL INJURY AND DEATH Wear Safety Equipment: Always wear ANSI-approved safety goggles and heavy-duty work gloves during • setup. Wear goggles when working with refrigerants. Contact with refrigerants may cause serious injury. Wear gloves when working with refrigerants to prevent chemical burns or other injuries. Prevent Leaks or Explosions: Incorrect use or connections may cause leaks or explosions.
  • Page 7: Overview (Product Information)

    OVERVIEW (PRODUCT INFORMATION) PACKAGE CONTENTS SKU 71093 / 71095 / 71096 INSTRUCTION MANUAL 1 PC(S) 2 5 0 VACUUM PUMP OIL 2 0 0 V A C U 1 PC(S) P U M P O I L D e s ig...
  • Page 8: Operation

    BEFORE USE INSTRUCTION Fill the Vacuum Pump with Oil: Unscrew the oil filling port/oil gas separator on models 71093, 71095, and • 71096. Fill the pump with TW vacuum pump oil.
  • Page 9: Components And Functions

    OPERATION COMPONENTS AND FUNCTIONS HANDLE GAS INLET ELECTRICAL BOX OIL/GAS SEPARATOR POWER SWITCH OIL LEVEL SIGHT GLASS OIL PLUG BASEBOARD MOTOR FEATURES 1. Anti-Backflow Design: The gas inlet passage is specially designed to prevent oil from flowing back, protecting the container and hoses from contamination. 2.
  • Page 10: Maintenance

    MAINTENANCE SAFETY WARNINGS AND MAINTENANCE INSTRUCTIONS To Prevent Serious Injury from Accidental Operation: Turn the tool’s power switch OFF and unplug the • tool from its electrical outlet before performing any inspection, maintenance, or cleaning procedures. To Prevent Serious Injury from Tool Failure: Do not use damaged equipment. If abnormal noise or vibra- •...
  • Page 11: Troubleshooting

    MAINTENANCE TROUBLESHOOTING PROBLEM POSSIBLE CAUSE LIKELY SOLUTIONS Tool will not start Cord not connected. Ensure the cord is securely plugged-in. No power at outlet. Check for power at the outlet. If the outlet is unpowerd: • Turn off the tool and check the circuit breaker.
  • Page 12: Replacement Parts

    REPLACEMENT PARTS REPLACEMENT PARTS PARTS DIAGRAM 3334 37 38 21 21 21 21 ITEM NO. DESCRIPTION ITEM NO. DESCRIPTION ITEM NO. DESCRIPTION BASEBOARD SPRING MOTOR STATOR SCREW STRAIGHT PIN BEARING RUBBER FEET BACK COVER CENTRIFUGE SCREW SCREW MOTOR ROTOR BRACKET O-RING BEARING STAINER...
  • Page 13: Disclaimer

    DISCLAIMER DISCLAIMER PLEASE READ THE FOLLOWING CAREFULLY The manufacturer and/or distributor have provided the parts list and assembly diagram in this manual for reference purposes only. They do not make any representation or warranty to the buyer that they are qualified to make repairs to the product or replace any parts of the product.
