Woodhaven 8350 Manual

Identify and verify that you have all the
parts listed. You'll need a #3 Phillips screwdriver
and a flat blade screwdriver for assembly.
Install your trim router on the
plate using the 10mm screws (MP010)
Outside holes for
PC 450 & DW611
Inside holes for
DWE6000
8350P
8350
Bushing Plate
Please Read Carefully!
Parts List:
Part Description
8350P DWE6000, DW611 & PC450 Plate . . . . . . . . .1
MP010 4mm x 10mm screws . . . . . . . . . . . . . . . . . . . .4
MF020 1-1/4" Screw . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
BUSH004 5/8" Spacer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
5590 Knob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
a bushing in the plate, you'll want
to center the router on the bushing.
the plate are oversize so you
can move the router slightly
and center it on the bushing.
Quantity
If you're using the router with
The mounting holes in
MP010 x4
