START HERE
GO TO SECTION V
"TESTING FOR
POWER TO THE
™
EC-17 CONTROLLER"
20
SECTION III - INSPECTION FOR ILLUMINATED LEDs
INSPECT THE EC-17 ™ CONTROLLER
FOR PRESENCE OF ILLUMINATED LEDS
AND RECORD
IS GREEN VOLT LED ILLUMINATED?
YES
YES
IS GREEN LED FLASHING?
NO
ARE ANY RED LEDs ILLUMINATED?
YES
NOTE AND RECORD
THE CONDITION OF
ALL RED LEDs
GO TO SECTION IV "INSPECTION
FOR ILLUMINATED LEDs"
NO
NO
ARE ANY RED
LEDs
ILLUMINATED?
YES
REPLACE THE EC-17 ™
CONTROLLER
GO TO SECTION IX "TESTING FOR
NO
FALSE FAILURE INDICATION - CAUSED
BY WHEEL SPEED COMPONENTS"
FRT
MID
RER
RHT
LFT
TRC
MOD
SEN
ECU
VLT
™
EC-17 CONTROLLER
DIAGNOSTIC DISPLAY
GO TO SECTION V
"TESTING FOR POWER
™
TO THE EC-17
CONTROLLER"
