Front & Rear Fender Flares
(1) Contents:
(2) Tools required:
8mm and 10mm wrench.
1/4 inner hexagon socket
8mm and 14mm Socket Wrench
（If necessary，need Drill and Drill
bit for the screws，because we
cannot make sure your jeep have
corresponding screw holes）
BXG.1002
Advertisement
Related Manuals for HOOKE ROAD BXG.1002
Summary of Contents for HOOKE ROAD BXG.1002
- Page 1 BXG.1002 Front & Rear Fender Flares (1) Contents: (2) Tools required: 8mm and 10mm wrench. 1/4 inner hexagon socket 8mm and 14mm Socket Wrench （If necessary，need Drill and Drill bit for the screws，because we cannot make sure your jeep have...
- Page 2 About 1 hour, 2-3 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) To view the electronic version (BXG.1002), please scan the QR code.
- Page 3 (4) Installation instruction: Step 1： Unbox the Fender Flares.Then you will get the fender flares like the picture shows below. Step 2： Started on the passenger side, but you can do either first. And there just 6 screw holes on the vehicle.But the fender flare have two more holes on it.But if your jeep have the two holes.Then you can easily to install the fender flare with the corresponding screws, washers and nuts.But if not，...
- Page 4 Step 3： Then according to the corresponding screw holes install the front fender flare.And according to the fender flare’s holes to choose the 3 kind of screws. As shown below. How to install the bolts: (1)Part “A” ,Part “G” ,Part “H” will be install together ;...
- Page 5 Step 4: The rear fender flare have 10 screws on it,but the jeep just have 8 corresponding screw holes.So the installation of rear fender flare just like what we said in step 2.
- Page 6 Step 5: After the step 4,then repeat the method of the step 3.
- Page 7 Step 6： Now the passenger side will be complete installation. Step 7： The installation method on the driver side is the same as the one on the passenger side. Step 8： Installation completed.
- Page 8 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product. 2.Please feel free to contact your distributor if you have any kind of question about your purchase. Hooke Road to find your parts...
