- Page 1 Fender Flares BXG.2005 (1)Contents: (2)Tools required: a.13/14mm Wrench; b.13/14mm Socket Wrench; c.One Drill; d.11mm Drill bit; e.M8 Pneumatic Rivet Nut Setting Kit...
-
Page 2: Installation Instruction
(3)Installation time: About 2 hours, 2-3 persons needed. Installation time is different according to individual person （ ） (4)Installation instruction: Step 1: Remove the original fender flares,and then ready to install the new fender flares. As shown below. Step 2: Install the front part first. - Page 3 Step 3: Tighten the front fender flare with PART”J”, PART”L” & PART”M”, by 13/14mm wrench & 13/14mm socket wrench. Step 4: Repeat the same method like “Step 2”.
- Page 4 Step 5: Install the PART”B”(the drive side). (1)Install the PART“N” on the bolt holes by the M8 Pneumatic Rivet Nut Setting Kit. (2)Then install the fender flare with PART“H” or PART“I” & PART“K”. Use PART“H” or PART“I” is according to the length.
- Page 5 (3)The figure shows there are two bolt holes,just install with PART“H” or PART“I”,this is according to the length too.And don’t forget to tighten it. Step 6: Repeat above steps to install another side.
- Page 6 Step 7: Installation completed. Attention: 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product. 2.Please feel free to contact us if you have any kind of question about your purchase.
