- Page 1 BXG.1012-S Front Bumper (1) Contents:...
- Page 2 Part Name Size(mm) Picture Hex Bolts M12*30 Hex Bolts M8*20 Split Lock Washer Split Lock Washer Flat Washer M12*30*2 Flat Washer M8*16*1.2 (2) Tools required: a.19mm Wrench； b.19mm Socket Wrench；...
- Page 3 About 1 hour, 2-3 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) To view the electronic version (BXG.1012-S), please scan the QR code.
- Page 4 (4) Installation instruction: Step 1: Remove the original front bumper. Step 2: Assemble the bull bar & the bumper with the Hex Bolts (M8*20), Split Lock Washer (D8), Flat Washer (M8*16*1.2).
- Page 5 Step 3: Install the bumper on the jeep.As shown on the RIGTH. Step 4: Use 19mm Socket Wrench or 19mm Wrench to tighten the bumper with the Hex Bolts (M12*30), Split Lock Washer (D12), Flat Washer (M12*30*2). (1) First,Install the upper bolt holes.
- Page 6 (2)Second,install the bottom bolt hole. Step 5: Install another side in the same method. Step 6: Install the D-rings.
- Page 7 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product. 2.Please feel free to contact your distributor if you have any kind of question about your purchase. Hooke Road to find your parts...
