INSTRUCTION & SAFETY MANUAL
SIL 3 Digital Output Driver
NE Loads Loop Powered
DIN-Rail Model D1048S
D1048 - SIL 3 Digital Output Driver NE Loads Loop Powered
ISM0096-9
