GMI D1093S Instruction & Safety Manual

Sil 3 relay output module with line and load diagnostics

Advertisement

Quick Links

D1093S
INSTRUCTION & SAFETY MANUAL
SIL 3 Relay Output Module
with Line and Load diagnostics
DIN-Rail Model D1093S
D1093 - SIL 3 Relay Output Module with Line and Load diagnostics
ISM0093-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D1093S and is the answer not in the manual?

Questions and answers

Summary of Contents for GMI D1093S

  • Page 1 D1093S INSTRUCTION & SAFETY MANUAL SIL 3 Relay Output Module with Line and Load diagnostics DIN-Rail Model D1093S D1093 - SIL 3 Relay Output Module with Line and Load diagnostics ISM0093-12...
  • Page 2 Characteristics General Description: The single channel DIN Rail Relay Output D1093S is a relay module suitable for the switching of safety related circuits, up to SIL 3 level according to IEC61508:2010 Ed. 2 for high risk industries. It provides isolation between the input and output contact.
  • Page 3 Ordering information Power Bus and DIN-Rail accessories: Model: D1093S DIN rail anchor MCHP065 DIN rail stopper MOR016 Power Bus enclosure Terminal block male MOR017 Terminal block female MOR022 Front Panel and Features  SIL 3 according to IEC 61508:2010 Ed. 2 for Tproof = 14 / 20 years (≤10% / >10 % of total SIF) with NE Load.
  • Page 4 Function Diagram SAFE AREA, ZONE 2 GROUP IIC T4, NON HAZARDOUS LOCATIONS, CLASS I, DIVISION 2, GROUPS A, B, C, D T-Code T4, CLASS I, ZONE 2, GROUP IIC T4 MODEL D1093S Load Power DC/AC max. 125 Vdc, 250 Vrms...
  • Page 5 Safety Function and Failure behavior: D1093S is considered to be operating in Low Demand mode, as a Type A module, having Hardware Fault Tolerance (HFT) = 0. In this Functional Safety application, the normal state operation of relay module is energized, with NE (Normally Energized) load.
  • Page 6 Safety Function and Failure behavior: D1093S is considered to be operating in Low Demand mode, as a Type A module, having Hardware Fault Tolerance (HFT) = 0. In this Functional Safety application, the normal state operation of relay module is de-energized, with ND (Normally De-energized) load.
  • Page 7 Supply diagnostic circuit (terminals “9-11” and “10-12”) and watch LEDs or fault output for verification. For D1093S single channel, verify input-output functionality for two different application: 1. normally energized (NE) loads (terminals “5” and “6”): supply input channel (terminals “13” & “14”) and verify that load is energized; then shutdown input channel and verify that load is de-energized (safe state).
  • Page 8 Installation D1093 is a relay output modules housed in a plastic enclosure suitable for installation on T35 DIN Rail according to EN50022. D1093 unit can be mounted with any orientation over the entire ambient temperature range, see section “Installation in Cabinet” and "Installation of Electronic Equipments in Cabinet" Instruction Manual D1000 series for detailed instructions. Electrical connection of conductors up to 2.5 mm²...
