- Page 1 D5090S-086 INSTRUCTION & SAFETY MANUAL 5 A SIL 3 Relay Output Module for NE Load, DIN-Rail and Termination Board, Model D5090S-086 D5090-086 - 5 A SIL 3 Relay Output Module for NE Load G.M. International ISM0267-4...
- Page 2 Characteristics General Description: The single channel Relay Output, D5090S-086 is a relay module suitable for the switching of safety related circuits, up to SIL 3 level according to IEC 61508:2010 Ed.2 for high risk industries. It provides isolation between input and output contacts.
- Page 3 Ordering Information DIN-Rail accessories: Cover and fix MCHP196 Model: D5090S-086 Front Panel and Features SIL 3 according to IEC 61508:2010 Ed.2 for Tproof = 6 / 20 yrs (≤10% / >10 % of total SIF). PFDavg (1 year) 1.44 E-05, SFF 96.70% for NE Load.
- Page 4 Function Diagram SAFE AREA, ZONE 2 GROUP IIC T4, NON HAZARDOUS LOCATIONS MODEL D5090S-086 (NC2) 11 Out 1 (NC contact) (CM1) 7 (CM1) 9 Service Load Out Not SIL (NO1) 10 (NC1) 8 Out 2 (NC contact) (NC3) 12 Termination...
- Page 5 Safety Function and Failure behavior: D5090S-086 is considered to be operating in Low Demand mode, as a Type A module, having Hardware Fault Tolerance (HFT) = 0. In the 1st Functional Safety application, the normal state operation of relay module is de-energized, with NE (Normally Energized) load.
- Page 6 Safety Function and Failure behavior: D5090S-086 is considered to be operating in Low Demand mode, as a Type A module, having Hardware Fault Tolerance (HFT) = 0. In the 2nd Functional Safety application, the normal state operation of relay module is de-energized, with NE (Normally Energized) load.
- Page 7 D5090S-086 relay module is suitable for the switching of safety related circuits, providing isolation between the input and output contacts. D5090S-086 provides two NC contacts for normally energized load and a NO contact for service purpose, in order to switch the NE load on both supply lines.
- Page 8 Start-up Before powering the inputs of unit check that all wires are properly connected, also verifying their polarity. Check conductors for exposed wires that could touch each other causing dangerous unwanted shorts. Enabling input, the “RELAY STATUS” yellow led must be lit and load circuit must be de-energized because relay output contacts (Out 1 and Out 2) are open. Indeed, disabling input, the “RELAY STATUS”...
