- Page 1 REV: 0 MB1200-B - Assembly Instructions Crusher HD Front Bumper MB1200-B - CRUSHER HD FRONT BUMPER COMPATIBLE WITH JEEP JL/JLU/JT ASSEMBLY INSTRUCTIONS motobilt.com | 334-219-2333...
- Page 2 REV: 0 MB1200-B - Assembly Instructions Crusher HD Front Bumper CONTENTS MB1200-10 Qty 1 MB1200-11 Qty 1 MB1200 Qty 1 NUTSTRIP: DRIVER NUTSTRIP: PASSENGER QTY 1 QTY 1 FRAME BRACKET - PASSENGER FRAME BRACKET - DRIVER Qty 1 Qty 1 7/16"-14 - NYLOCK HEX NUT...
- Page 3 REV: MB1200-B - Assembly Instructions MB1200-10 (3) 3/8" - FLAT WASHER (3) 3/8"-16 - HEX NUT MB1200-11 (3) 3/8" - FLAT WASER (3) 3/8"-16 x 1" - HEX BOLT WINCH PLATE ASSEMBLY AFTER ASSEMBLY motobilt.com | 334-219-2333...
- Page 4 FRAME BRACKET - DRIVER NUTSTRIP - DRIVER (2) 3/8"-16 x 1" - HEX BOLT (2) 3/8" - FLAT WASHER FACTORY BOLT FRAME BRACKET - PASSENGER NUTSTRIP - PASENGER (2) 3/8"-16 x 1" - HEX BOLT (2) 3/8" - FLAT WASHER motobilt.com | 334-219-2333...
- Page 5 REV: 0 MB1200 - Assembly Instructions Crusher HD Front Bumper (4) 3/8"-16 x 1" - HEX BOLT (4) 3/8" - FLAT WASHER (4) 3/8" - FLAT WASHER (4) 3/8"-16 - HEX NUT WINCH PLATE INSTALLATION motobilt.com | 334-219-2333...
-
Page 6: Bumper Installation
REV: 0 MB1200 - Assembly Instructions Crusher HD Front Bumper NOTE: INSTALL FOGLIGHTS AND TIGHTEN LIGHTS SECURELY BEFORE INSTALLING BUMPER ON FRAME. (8) 7/16" - FLAT WASHER (8) 7/16"-14 - HEX NUT BUMPER INSTALLATION motobilt.com | 334-219-2333...
