- Page 1 REV: MB5063 - Assembly Instructions JLU Wrangler Full Cab Roof Rack MB5063 - JLU WRANGLER FULL CAB ROOF RACK ASSEMBLY INSTRUCTIONS motobilt.com | 334-219-2333...
- Page 2 REV: MB5063 - Assembly Instructions JLU Wrangler Full Cab Roof Rack CONTENTS MB5063-11 Rubber Edge Trim MB5063-01 MB5063-02 Rubber Strip Qty 6 Vinyl End Cap Qty 6 MB5063-07 Qty 2 MB5063-04 Qty 7 MB5063-03 MB5063-06 - Weldment, Mount Qty 2...
- Page 3 REV: MB5063 - Assembly Instructions JLU Wrangler Full Cab Roof Rack ASSEMBLY STEP 01 1/4"-20 x .75" Button Head Socket Screw MB5063-01 MB5063-11 1/4"-20 x .75" Button Head Socket Screw 1/4"-20 Nylon-Insert Locknut 1/4"-20 Nylon-Insert Locknut MB5063-03 Qty 2 MB5063-04...
- Page 4 REV: MB5063 - Assembly Instructions JLU Wrangler Full Cab Roof Rack ASSEMBLY STEP 02 Middle Mount Front / Rear Mount DO NOT TIGHTEN BOLTS ALL THE WAY AT THIS TIME TO DRIP RAIL MOUNT MB5063-06 Weldment, Mount MB5063-09 Weldment, Mount...
- Page 5 REV: MB5063 - Assembly Instructions JLU Wrangler Full Cab Roof Rack ASSEMBLY STEP 03 REMOVE RED TAPE BACKING AFTER PLACING TRIM ON FRONT AIR DAM. TRIM EXCESS EDGE TRIM IF NEEDED. motobilt.com | 334-219-2333...
- Page 6 REV: MB5063 - Assembly Instructions JLU Wrangler Full Cab Roof Rack ASSEMBLY STEP 04 LOWER RACK ONTO DRIP RAIL, A SECOND PERSON CAN HELP MAKE THIS EASIER AFTER SECURING THE ROOF RACK MOUNT TO THE DRIP RAIL GO BACK AND TIGHTEN THE BOLTS FROM STEP 02 motobilt.com | 334-219-2333...
