TrailFX B1614T Assembly, Installation, Operation And Maintenance Instructions

Dealer / Installer: Provide a copy of these instructions to the end user of this product. These instructions
provide important operating and safety information for proper usage of this product.
Demonstrate the proper use of the product with the end user. Have the end user
demonstrate that they understand the proper use of the product.
End User: Read and follow all instructions included in this manual. Ask your Dealer / Installer for
assistance if you do not understand the proper use of the product. Never remove any
WARNING
decals from the product. Failure to follow these instructions can result in injury or death.
APPLICATION
: 2022-2023 TOYOTA TUNDRA
Qty
3-1/2" Oval Bull Bar
1
1 Driver/Left Frame Mounting Bracket
1 Passenger/Right Fame Mounting Bracket
1 Driver/Left Support Bracket
1 Passenger/Right Support Bracket
1 Driver/Left Bull Bar Bracket
1 Passenger/Right Bull Bar Bracket
2
Size
10 MM
Passenger/Right
Frame Mounting
Bracket
Passenger/Right
Bull Bar Bracket
Visit www.trailfx.com
Assembly, Installation, Operation and
Maintenance Instructions
3.5" Oval Bull Bar
Part Description
10mm Fish Wires
TORQUE SPECIFICATION
Torque
34.5 ft/lbs
Passenger/Right
Support Bracket
or Call (866) 638-4870 for Warranty Information / Tech Support / Product Updates.
Keystone Automotive Operations Inc. All Rights Reserved. 11/15/2022-R01
PARTS LIST
Qty
2
6
14
8
8
4
2
6
6
Size
08 MM
(2) 10mm Bolt
Plates
Driver/Left
Support Bracket
(2) 10mm Fish Wire
Part Number:
B1614T
60 - 180 minutes
Part Description
10mm x 35mm Bolt Plates
10-1.5mm x 35mm Hex Bolts
10mm x 30mm x 2.5mm Flat Washers
10mm Lock Washers
10mm Hex Nuts
8-1.25mm x 35mm Hex Bolts
8-1.25mm x 16mm Hex Bolts
8mm x 24mm x 2mm Flat Washers
8mm Lock Washers
Torque
20.0 ft/lbs
Driver/Left Bull Bar
Bracket
Driver/Left Frame
Mounting Bracket
Page-1-5
