WARNING
APPLICATION
: 2021- 2022 Ford Bronco (For Standard & Winch Mount Bumpers)
INSTALLATION PROCEDURE:
REMOVE CONTENTS FROM BOX AND VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS CAREFULLY.
ASSISTANCE IS RECOMMENDED.
1. Start installation from under the front of the vehicle. Remove the splash guard from below/behind the bumper, (Figures 1 &
2).
2. Select the Skid Plate, (Figure 3).
3. With assistance, hold the Skid Plate up to the bottom of the vehicle. Line up the holes in the Skid Plate with the factory
splash guard mounting brackets. Reuse the factory mounting bolts for the splash guard to attach the front of the Skid Plate,
(Figure 3). Reuse the factory hex bolts to attach the rear of the Skid Plate to the bottom of the frame.
4. Check the Skid Plate alignment with the vehicle and fully tighten all hardware at this time.
5. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
To protect your investment, do not use any type of polish or wax that may contain abrasives that could damage the finish. Mild soap may
be used to clean the Skid Plate.
Visit
www.trailfx.com
Assembly, Installation, Operation and
Maintenance Instructions
Ford Bronco Bumper Skid Plate
Provide a copy of these instructions to the end user of this product. These instructions
provide important operating and safety information for proper usage of this product.
Demonstrate the proper use of the product with the end user. Have the end user
demonstrate that they understand the proper use of the product.
Read and follow all instructions included in this manual. Ask your Dealer / Installer for
assistance if you do not understand the proper use of the product. Never remove any
decals from the product. Failure to follow these instructions can result in injury or death.
Qty
1
Skid Plate
or 1 (866) 638-4870 for Warranty Information / Tech Support / Product Updates.
2021 Keystone Automotive Operations Inc. All Rights Reserved. 05/19/2022-R01
PARTS LIST
Part Description
Skid Plate
Part Number:
BR003T
60 - 180 minutes
Page-1-3
