    Thank you for purchasing this product To ensure the best performance and safety, it is imperative that you carefully read these instructions prior to connecting, operating, or adjusting this product. It is advised that you retain this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.
  • Page 3: Introduction

    1. Introduction The KanexPro SP-1X4A8K 8K HDMI 1x4 Splitter has the ability to distribute a single HDMI source signal to two display devices. This product supports video resolution of up to 8K at 60Hz and 4:2:0, and also features advanced EDID management and audio de-embedding functionality, with audio out- put available through both optical and analog ports.
  • Page 4: Specifications

    4. Specifications Technical HDMI Compliance HDMI 2.1 HDCP Compliance HDCP 2.3 Video Bandwidth 40Gbps Video Resolution Up to 8K@60Hz 4:2:0 10bit, 8K@30Hz 4:4:4 10bit, 4K@120Hz 4:4:4 10bit Color Depth 8/10/12-bit Color Space RGB, YCbCr 4:4:4 / 4:2:2. YUV 4:2:0 Audio Formats HDMI input/output: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD...
  • Page 5 Weight 539g Power Supply Input: AC100 - 240V 50/60Hz, Output: DC 5V/2A (US/EU standards, CE/FCC/UL certified) Power Consumption 9W (Max) Operation 0°C ~ 40°C / 32°F ~ 104°F Temperature Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F Relative Humidity 20~90% RH (non-condensing) Recommended HDMI Cable Video Resolution...
  • Page 6: Operation Controls And Functions

    5. Operation Controls and Functions Front Panel Rear Panel Name Function Description POWER LED The power LED lights in green when the device is working. IN LED When the HDMI IN port connects an active source device, the green LED will be on. OUT LED (1~4) When the HDMI OUT 1/2/3/4 port connects a display device and outputs signal, the...
  • Page 7 OUT port (1~4) HDMI signal output port, connecting to HDMI display device such as TV or Monitor with an HDMI cable. OPTICAL Optical fiber audio output port. Analog audio output port. EDID DIP Use the DIP switch to set EDID. switch 111.
  • Page 8: Application Example

    6. Application Example The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
