KanexPro SP-HD1X28K User Manual

8k 2-port hdmi 2.1 splitter
Hide thumbs

Advertisement

Table of Contents

8K 2-Port
HDMI 2.1 Splitter
User Manual
SKU: SP-HD1X28K
8 8 8 . 9 7 5 . 1 3 6 8 | S U P P O R T @ K A N E X P R O . C O M | K A N E X P R O . C O M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-HD1X28K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KanexPro SP-HD1X28K

Summary of Contents for KanexPro SP-HD1X28K

  • Page 1 User Manual SKU: SP-HD1X28K 8 8 8 . 9 7 5 . 1 3 6 8 | S U P P O R T @ K A N E X P R O . C O M | K A N E X P R O . C O M...

  • Page 2: Table Of Contents

    Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.

  • Page 3: Introduction

    1. Introduction The KanexPro SP-HD1X28K 1x2 splitter is an advanced solution for splitting single HDMI signal to 2 HDMI outputs synchronously, with video resolution up to 8K@60 4:2:0 12bit. It supports data rates up to 48Gbps to comply with HDMI 2.1 and HDCP 2.3 requirements.

  • Page 4: Specifications

    4. Specifications Technical HDMI Compliance HDMI 2.1 HDCP Compliance HDCP 2.3 Video Bandwidth 48Gbps FRL and 18Gbps TMDS Video Resolution Up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit Color Depth 8/10/12-bit Color Space RGB, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0 HDMI input/output: LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, Audio Formats DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD HDR, HDR10, HDR10+, Dolby Vision, HLG...

  • Page 5: Operation Controls And Functions

    Recommended HDMI Cable Video Resolution 4K60 4K24 1080P HDMI Cable Length 3m/10ft 8m/26ft 12m/39ft 15m/49ft (HDMI IN / OUT) (Ultra HDMI 2.1) The use of “Premium High Speed HDMI” cable is highly recommended. 5. Operation Controls and Functions Front Panel OUT 1 OUT 2 EDID...

  • Page 6: Auto Downscaling & Auto Converting

    Name Function Description Use the DIP switch to set EDID. [DIP]=111: Copy OUT 1 port sink EDID (as factory default) [DIP]=110: 4K60 (4:4:4), 2.0CH [DIP]=101: FRL12G_8K_HDR, 2.0CH EDID DIP [DIP]=100: FRL12G_8K_HDR, 5.1CH switch [DIP]=011: FRL12G_8K_HDR, 7.1CH [DIP]=010: FRL10G_8K_HDR, 2.0CH [DIP]=001: FRL10G_8K_HDR, 5.1CH [DIP]=000: FRL10G_8K_HDR, 7.1CH SERVICE Firmware update port.
  • Page 7 Bypass Splitter 8K HDR TV 4K HDR 4K Source 4K HDR Downscaling & Converting 1080P SDR TV 1080P SDR Bypass Splitter 4K HDR TV 4K HDR 4K Source 4K HDR Downscaling & Converting 1080P DVI TV (No sound) 1080P DVI Bypass Splitter 4K HDR TV...

  • Page 8: Application Example

    Downscaling will not work in the following conditions: 1. The input source is 8K DSC format. 2. The resolution of input source is not supported by the splitter. 7. Application Example DVD or Blu-ray Player Power Supply OUT 1 OUT 2 DC 5V 8K TV 2 8K TV 1...
