Summary of Contents for Satel GSM-X Plus
- Page 1 Communication module GSM-X Plus Firmware version: 2.00 QUICK INSTALLATION GUIDE gsm-x_plus_sii_en 10/24 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 Direct current (DC). FreeRTOS is used in this device (www.freertos.org). SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
-
Page 3: Table Of Contents
CONTENTS GSM-X Plus module installation ..................2 Preparing the cabling ....................2 Installation of enclosure ....................2 1.2.1 Elements inside the enclosure ................3 1.2.2 Electronics board ....................4 1.2.3 Antenna ........................ 5 Connecting the analog telephone line ................. 5 Connecting the devices to the inputs and outputs ............ -
Page 4: Gsm-X Plus Module Installation
• 2-pole disconnector, • short-circuit protection with a 16 A time delay circuit breaker. The GSM-X Plus module should be installed indoors, in spaces with normal air humidity. When selecting the mounting location, remember that thick masonry walls, metal partitions, etc. -
Page 5: Elements Inside The Enclosure
SATEL GSM-X Plus The module can also be installed in SATEL’s OPU-4 P enclosure. It is recommended that you use this enclosure, if you are planning to install the GSM-X-ETH Ethernet module / the GSM-X-PSTN telephone module on the electronics board or the module is to be powered from a power supply connected to the APS connector (e.g. -
Page 6: Electronics Board
RS-232 port. USB socket (Micro-B). APS connector for a SATEL power supply (e.g. APS-412). connectors for the GSM-X-ETH module (see “GSM-X-ETH module installation” p. 8) / GSM-X-PSTN module (see “GSM-X-PSTN module installation” p. 9). -
Page 7: Antenna
[from telephone provider] or the GSM-X-PSTN module). 1.2.3 Antenna The GSM-X Plus module is delivered with an antenna installed inside the enclosure. The antenna can be replaced with an external antenna mounted on the enclosure or at some distance from it. If this is the case, you will need the IPX-SMA adapter. -
Page 8: Connecting The Devices To The Inputs And Outputs
1.5 Connecting the RS-232 port If the module is to work in conjunction with the INTEGRA / INTEGRA Plus control panel, connect together the RS-232 ports on module and control panel. Use the SATEL RJ/PIN5 cable. Fig. 6. Connecting the RS-232 ports on module and computer. Shown on the left is PIN-5... -
Page 9: Connecting Devices To The Rs-485 Communication Bus
RS-232 port to the port of computer on which the cards are installed. If the computer has a USB port, use the SATEL USB-RS converter. If the computer has a RS-232 port, make a connection according to Fig. 6. -
Page 10: Installing The Sim Cards
1. Use the GX Soft program to configure settings of the GSM-X-ETH Ethernet module (see full manual of the GSM-X Plus module). 2. Power down the GSM-X Plus module. 3. Install the GSM-X-ETH Ethernet module in the connectors on the GSM-X Plus module electronics board (Fig. 9). -
Page 11: Gsm-X-Pstn Module Installation
1. Use the GX Soft program to enable the GSM-X-PSTN telephone module support (see the full manual to the GSM-X Plus module). 2. Power down the GSM-X Plus module. 3. Install the GSM-X-PSTN module in the connectors on the GSM-X Plus module electronics board (Fig. 10). Fig. 10. Installing the GSM-X-PSTN module. - Page 12 ADSL filter (Fig. 11). 6. Connect terminals T-1 and R-1 of the GSM-X Plus module to terminals TIP and RING of the control panel (Fig. 11). Any telephone located on the premises can be connected to terminals T-1 and R-1 of the control panel.
