- Page 1 GPRS-A Universal monitoring module Quick installation guide Full manual is available on www.satel.eu Firmware version 1.02 gprs-a_sii_en 08/18 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • Poland tel. +48 58 320 94 00 www.satel.eu...
- Page 2 The name plate of the device is located on the enclosure base. FreeRTOS is used in this device (www.freertos.org). SATEL's goal is to continually upgrade the quality of its products, which may result in some changes of their technical specifications and firmware. The current information on the introduced modifications is available on our website.
- Page 3 2-pole disconnector, short-circuit protection with a 16 A time delay circuit breaker. The GPRS-A module should be installed indoors, in spaces with normal air humidity. When selecting the mounting location, remember that thick masonry walls, metal partitions, etc. will reduce the range of radio signal.
- Page 4 – input for supervision of AC voltage presence. 1.2.1 Antenna The GPRS-A module is delivered with an antenna. The antenna can be replaced with another antenna mounted on the enclosure or at some distance from it. Using the antenna mounted at some distance from the enclosure is recommended wherever thick masonry walls, metal partitions etc.
- Page 5 30 meters. If several sensors are to be connected to the bus, it is recommended that you use the distribution box module (MZ-2 or MZ-3). SATEL's product offering includes the DS-T1 waterproof temperature sensors. They make it possible to measure temperatures ranging from -35°C to 60°C. They are designed for surface mounting indoors or outdoors.
- Page 6 The module may be powered from the control panel, from an expander with power supply, or from a power supply unit with current limitation up to 3 A. SATEL offers power supplies (e.g. APS-612), which can be connected to the APS connector on the electronics board.
-
Page 7: Specifications
SATEL GPRS-A Restarting the module with a wrongly programmed PIN code three times will block the SIM card. To unblock the SIM card, remove it and insert into a mobile phone. Then, enter the PUK code. 2. Specifications Number of inputs ........................8 Number of outputs OC type .................
